Numerical Analysis of the Influence of a Winglet Actuated Control Surface by Means of Direct and Reduced-Order-Model Simulation

Bae Hong Chen (Broschiert, Englisch)

Keine Bewertungen vorhanden

Optischer Zustand

Beschreibung

The usage of Computational Aero-Structural Dynamics (CASD) and different kinds of Reduced Order Models (ROM) methods for the preliminary design of new airplane concepts and the validation of such tools have been the matter of many research programs in recent years. This includes especially the prediction of dynamic aeroelastic phenomena, which are caused by the interaction of the wing's elastic and inertial properties with the ambient flow. The prediction of these phenomena is still very challenging. In this context, the transfer project Aero-Structural Dynamics Methods for Airplane Design (ASDMAD) was initiated. Herein, a new winglet concept with an additional movable control surface (WACS) was constructed, built and tested. The purpose of this work is the assessment of the functionality and efficiency of the WACS by means of the numerical method SOFIA. Furthermore, a ROM method is developed to predict the unsteady wing deformation due to forced vibrations by means of the root excitation mechanism and the harmonically moved WACS for the use in a feedback control system. The investigated wing geometry is based on the redesigned supercritical wing model from the HIRENASD project. The modifications were mainly focused on the wing-tip region, which was shortened for the attachment of different winglets. According to the applicability of the WACS, the investigation is divided into two parts, in which the control surface in the computations is assumed to be free from rotational inertia and massless. First, the static usage is studied with the WACS at fixed deflection angles. The main purpose of a static usage is to reduce structural deformations and loads caused by the winglet, and thus, to expand the cruise condition range in which the winglet is effective. In the second part of the investigation, the influence of a dynamically operated ACS is studied for three different applications. This includes the observation of the ACS effect on an aeroelastic equilibrium state during decay process and forced vibration. In the last part of this work, the applicability of the ROM method is demonstrated by means of two wing configurations, one being the ASDMAD-2 configuration including the WACS. It is shown that the method is highly accurate for the rapid computation of unsteady aerodynamic and aeroelastic responses. This is also the case if only the first-order linear kernel is used in favor of reducing the computational effort for the kernel identification. Weniger zeigen

Dieses Produkt haben wir gerade leider nicht auf Lager.

ab 45,99 €

Derzeit nicht verfügbar

Handgeprüfte Gebrauchtware

Bis zu 50 % günstiger als neu

Der Umwelt zuliebe

Produktinformationen

Technische Daten

Erscheinungsdatum

07.06.2015

Sprache

Englisch

EAN

9783843921329

Herausgeber

Dr. Hut

Serien- oder Bandtitel

Luftfahrt

Sonderedition

Nein

Autor

Bae Hong Chen

Seitenanzahl

137

Einbandart

Broschiert

Schlagwörter

Winglet, Direct-Order-Model Simulation, Reduced-Order-Model Simulation

Thema-Inhalt

T - Technologie, Ingenieurswissenschaft, Landwirtschaft TRP - Luft- und Raumfahrttechnik TR - Verkehrstechnik und Transportwesen

Höhe

210 mm

Breite

14.8 cm
