Grid Converters for Photovoltaic and Wind Power Systems
Remus Teodorescu, Marco Liserre, Pedro Rodríguez (Gebundene Ausgabe, Englisch)
Keine Bewertungen vorhanden
Optischer Zustand
Beschreibung
Grid converters are the key player in renewable energy integration. The high penetration of renewable energy systems is calling for new more stringent grid requirements. As a consequence, the grid converters should be able to exhibit advanced functions like: dynamic control of active and reactive power, operation within a wide range of voltage and frequency, voltage ride-through capability, Dieses Produkt haben wir gerade leider nicht auf Lager.
Handgeprüfte Gebrauchtware
Bis zu 50 % günstiger als neu
Der Umwelt zuliebe
Technische Daten
Sprache
Englisch
EAN
9780470057513
Herausgeber
John Wiley & Sons
Autor
Remus Teodorescu, Marco Liserre, Pedro Rodríguez
Seitenanzahl
416
Einbandart
Gebundene Ausgabe
Inhaltsverzeichnis
About the Authors.
Preface.
Acknowledgements.
1 Introduction.
1.1 Wind Power Development.
1.2 Photovoltaic Power Development.
1.3 The Grid Converter - The Key Element in Grid Integration of WT and PV Systems.
2 Photovoltaic Inverter Structures.
2.1 Introduction.
2.2 Inverter Structures Derived from H-Bridge Topology.
2.3 Inverter Structures Derived from NPC Topology.
2.4 Typical PV Inverter Structures.
2.5 Three-Phase PV Inverters.
2.6 Control Structures.
2.7 Conclusions and Future Trends.
3 Grid Requirements for PV.
3.1 Introduction.
3.2 International Regulations.
3.3 Response to Abnormal Grid Conditions.
3.4 Power Quality.
3.5 Anti-islanding Requirements.
3.6 Summary.
4 Grid Synchronization in Single-Phase Power Converters.
4.1 Introduction.
4.2 Grid Synchronization Techniques for Single-Phase Systems.
4.3 Phase Detection Based on In-Quadrature Signals.
4.4 Some PLLs Based on In-Quadrature Signal Generation.
4.5 Some PLLs Based on Adaptive Filtering.
4.6 The SOGI Frequency-Locked Loop.
4.7 Summary.
5 Islanding Detection.
5.1 Introduction.
5.2 Nondetection Zone.
5.3 Overview of Islanding Detection Methods.
5.4 Passive Islanding Detection Methods.
5.5 Active Islanding Detection Methods.
5.6 Summary.
6 Grid Converter Structures forWind Turbine Systems.
6.1 Introduction.
6.2 WTS Power Configurations.
6.3 Grid Power Converter Topologies.
6.4 WTS Control.
6.5 Summary.
7 Grid Requirements for WT Systems.
7.1 Introduction.
7.2 Grid Code Evolution.
7.3 Frequency and Voltage Deviation under Normal Operation.
7.4 Active Power Control in Normal Operation.
7.5 Reactive Power Control in Normal Operation.
7.6 Behaviour under Grid Disturbances.
7.7 Discussion of Harmonization of Grid Codes.
7.8 Future Trends.
7.9 Summary.
8 Grid Synchronization in Three-Phase Power Converters.
8.1 Introduction.
8.2 The Three-Phase Voltage Vector under Grid Faults.
8.3 The Synchronous Reference Frame PLL under Unbalanced and Distorted Grid Conditions.
8.4 The Decoupled Double Synchronous Reference Frame PLL (DDSRF-PLL).
8.5 The Double Second-Order Generalized Integrator FLL (DSOGI-FLL).
8.6 Summary.
9 Grid Converter Control for WTS.
9.1 Introduction.
9.2 Model of the Converter.
9.3 AC Voltage and DC Voltage Control.
9.4 Voltage Oriented Control and Direct Power Control.
9.5 Stand-alone, Micro-grid, Droop Control and Grid Supporting.
9.6 Summary.
10 Control of Grid Converters under Grid Faults.
10.1 Introduction.
10.2 Overview of Control Techniques for Grid-Connected Converters under Unbalanced Grid Voltage Conditions.
10.3 Control Structures for Unbalanced Current Injection.
10.4 Power Control under Unbalanced Grid Conditions.
10.5 Flexible Power Control with Current Limitation.
10.6 Summary.
11 Grid Filter Design.
11.1 Introduction.
11.2 Filter Topologies.
11.3 Design Considerations.
11.4 Practical Examples of LCL Filters and Grid Interactions.
11.5 Resonance Problem and Damping Solutions.
11.6 Nonlinear Behaviour of the Filter.
11.7 Summary.
12 Grid Current Control.
12.1 Introduction.
12.2 Current Harmonic Requirements.
12.3 Linear Current Control with Separated Modulation.
12.4 Modulation Techniques.
12.5 Operating Limits of the Current-Controlled Converter.
12.6 Practical Example.
12.7 Summary.
Appendix A Space Vector Transformations of Three-Phase Systems.
A.1 Introduction.
A.2 Symmetrical Components in the Frequency Domain.
A.3 Symmetrical Components in the Time Domain.
A.4 Components ±²0 on the Stationary Reference Frame.
A.5 Components dq0 on the Synchronous Reference Frame.
Appendix B Instantaneous Power Theories.
B.1 Introduction.
B.2 Origin of Power Definitions at the Time Domain for Single-Phase Systems.
B.3 Origin of Active Currents in Multiphase Systems.
B.4 Instantaneous Calculation of Power Currents in Multiphase Systems.
B.5 The p-q Theory.
B.6 Generalization of the p-q Theory to Arbitrary Multiphase Systems.
B.7 The Modified p-q Theory.
B.8 Generalized Instantaneous Reactive Power Theory for Three-Phase Power Systems.
B.9 Summary.
Appendix C Resonant Controller.
C.1 Introduction.
C.2 Internal Model Principle.
C.3 Equivalence of the PI Controller in the dq Frame and the P+Resonant Controller in the ±² Frame.
Index.
Höhe
244 mm
Breite
16.8 cm
-.-
